Hikvision DS-K1802M Mifare Card Reader
- Meets the standard of ISO 14443-A and the card reading frequency is 13.56MHz. The number and content of MIFARE card can be read
- Watchdog design for repairing itself in case that exception occurs, to ensure the long service life of the reader
- Wiegand(w26, w34) protocol
- Built-in buzzer for identifying the reading status
- IP65 Standard
Power Supply |
12V DC |
Power Consumption |
≤2W |
Processor |
8-bit |
Reading Frequency |
13.56MHz |
Reading Range |
≤50mm (≤1.97") |
Radio Frequency Standard |
ISO 14443-A |
Audio Alert |
Beeper |
Keypad |
No Keypad |
LED Indicator |
Power Indicator, Status Indicator |
Working Temperature |
-20°C to +65°C (-4°F to 149°F) |
Working Humidity |
10% to 90% (Non Condensing) |
Dimensions |
115.9mm×43.3mm×17mm (4.56"×1.70"×0.67") |
Protection Level |
IP65 |
Installing Method |
Wall Mounting with Screws; Do Not Support Gang Box |
