  2-hardwired zones input






•


  Tamper input (L2)






•


  Low battery supervision






•


  Firmware upgradeable via 307USB





Compatible with all Magellan systems:

• MG5000/MG5050 v4.92, MG5050+ v1.00., MG5075 v1.03 or higher versions



• SP5500/SP6000/SP7000 v7.14 and higher (with an RTX3)



• SP4000/SP65 v5.40 and higher (with an RTX3)



• EVO192 and EVOHD v7.31 and higher (with an RTX3)



• BabyWare v5.4.8 and higher



• InField v5.5.2 and higher




Specifications

Power Input: 3 VDC, 9 VDC, or 12-13.8 VDC
RF Frequency: 433 MHz or 868 MHz
Low Battery Indication: Supervised every 12 hours
3V: Low battery at 2.5V
9V: Low battery at 6.7V
12V: Low battery at 10.5V
Battery Life/Current: 3 years in normal use (10 activations per day)
50 uA (average current consumption)
Number of Inputs: 2 zone inputs plus tamper connection
Operating Temperature: -20ºC to 50ºC
Humidity: 5 to 95%
Dimensions (H x W x D): 2 cm x 7 cm x 1 cm


Download the product information
