Description AJAX Hub 2 4G Black - Security system control panel with support for photo verification

In control of security, not your private life
Hub 2 manages all the Ajax devices in the system to alert users about open doors, broken windows, threats of fire and flooding. If burglars break into your facility, Hub 2 will notify the monitoring station 1and send photos from the MotionCam detectors. You won’t need to live under the constant supervision of the security cameras to know what’s going on.

•


  PRO anti-sabotage





•


  Alarm photo verification in 9 seconds





•


  Data-rich notifications





•


  Flexible security management of the facility





•


  Security automation





•


  New features with every update





•


  Up to 16 hours of backup battery life





•


  3 independent communication channels out of the box





•


  Hassle-free installation




Alarm photo verification in 9 seconds
Hub 2 works with MotionCam and MotionCam Outdoor motion detectors. When detectors are triggered, they take a series of photos. It helps to evaluate the situation at the facility. Visual verification helps you instantly assess the situation, relieving users of unnecessary anxiety, and security companies — from false calls of patrols.

Always connected — via cable and cellular networks
Communication with the outside world is critical for the security system control panel. Its reliability and stability guarantee timely alarm transmission to the security company and users.

Hub 2 can be simultaneously connected to three Internet service providers — via Ethernet cable and 2G, 3G, and LTE 2 cellular networks. The automatic switching between channels takes seconds.

Guaranteed delivery of alarms and visual alarm verifications
To ensure reliable communications, we have equipped Hub 2 with four antennas and support of two proprietary radio protocols: Jeweller and Wings. Jeweller is responsible for the transmission of commands, events, and alarms, while Wings provides batch transmission of images. Ajax two-way radio communication uses frames to synchronize device communication sessions, authentication to prevent fraud, and encryption to protect against data theft.
Learn more about Ajax radio communication

Flexibility at the core
The Hub 2 radio network covers several floors and separate buildings — thanks to the communication range of 2,000 meters and the ability to connect five range extenders. To manage access and security zoning of the facility, the hub allows connecting 50 users and creating 9 security groups. Hub 2 is a perfect choice for home and business security.

Controlled with apps
We refrained from control buttons on the control panel body and archaic interfaces — apps are more convenient and reliable. They connect to a hub via a secure channel through the Ajax Cloud server located in several AWS data centres. Server availability in 2021 was 99.995%.

Apps allow system users with administrator rights to manage the security of the facility, change settings of the hub and the devices connected to it, create scenarios, and monitor events. From a smartphone or a PC. On the site and remotely.

Automates security
Hub 2 allows creating 32 scenarios and minimizing the impact of human factor on security. The hub can arm and disarm a facility or a group by schedule. Instantly activate a smoke machine if someone enters the premises. Blackout the premises and turn on emergency lighting in case of fire. Or shut off the water in case of a leak. Control lights, electric locks, roller shutters, and garage doors — by arming/disarming, button press, or a detector alarm.

Resistant to sabotage
Whatever happens to Hub 2, the security company and the users will be notified. No one can disconnect the hub unnoticed when the facility is disarmed. If an intruder attempts to dismount the device, this will trigger the tamper immediately. The Ajax Cloud server can notify about the loss of connection with the hub in 60 seconds due to frequent polling. Even if the building is de-energized, the hub will protect the object for up to 16 hours with a built-in backup battery.

Future-proof
Hub 2 runs OS Malevich — a real-time operating system developed by Ajax Systems. OS Malevich is extremely stable, immune to viruses, and protected from cyberattacks. Modular architecture simplifies the constant upgrading of OS Malevich.

Hub receives new features several times a year with over-the-air updates. The update process is automatic and takes minutes when the security system is disarmed. The hardware configuration will allow Hub 2 to evolve and remain relevant for years to come.

Hassle-free installation
Hub 2 is ready to operate out of the box. All communication modules, power supply, and backup battery are already installed. To start setting up the system, you need to connect the device to the power supply and the Internet, insert the SIM cards, and scan the QR code through the app. With the SmartBracket mounting panel, there is no need to disassemble the device body during installation.

Connecting security devices, video cameras, users, testing the radio signal, creating groups and scenarios, even sending a request for connection to the CMS — all system settings are always available in the Ajax apps. Whether you are at the site or not.

Easy security system upgrade
To simplify updating hubs at the facilities, we have provided the ability to transfer data between them automatically. The import feature allows you to transfer settings, connected devices, groups, scenarios, and users from the old hub to Hub 2. In less than 15 minutes

Classification	Security system control panel
Colour	White Black
Installation type	Indoors
Maximum number of connected devices	Up to 100
Maximum number of connected radio signal range extenders	Up to 5
Video surveillance	Up to 25 cameras or DVRs
Users	Up to 50
Rooms	Up to 50
Scenarios	Up to 32 (Scenarios by arming/disarming are not included in the overall limit of the hub's scenarios)
Security groups	Up to 9
Communication channels	Hub 2 (4G): Ethernet two SIM cards 2G (GSM900/DCS1800 (B3/B8)) 3G (WCDMA 850/900/2100 (B1/B5/B8)) LTE (FDD B1/B3/B5/B7/B8/B20
Alarm delivery time	0.15 sec
Types of notifications	Push notifications Phone calls SMS (types of notifications depend on user settings)
Sending photo in case of an alarm	Photo delivery time under default settings: up to 9 seconds Photo resolution: up to 640×480 pixels Photos in a series: 1–5
Switching between 2G, 3G, LTE	Instantly available only on Hub 2 (4G)
Switching between SIM cards	4 minutes
Support of central monitoring station communication protocols	Sur-Gard (Contact ID), SIA (DC-09), proprietary protocols.
Support of monitoring software	PRO Desktop
Operating system	OS Malevich
Power supply	110−240 V, 50/60 Hz Consumption from the 110-240 V AC grid is up to 10 W 6 V⎓ with an alternative power supply unit 6V PSU 12 V⎓ with an alternative power supply unit 12V PSU
Backup battery	Li-Ion 2 Аh Up to 16 h of battery life with Ethernet disabled
Jeweller radio protocol	Communication range — up to 2000 meters in a line of sight Two-way communication between devices Radio frequency bands: 866.0 – 866.5 MHz 868.0 – 868.6 MHz 868.7 – 869.2 MHz 905.0 – 926.5 MHz 915.85 – 926.5 MHz 921.0 – 922.0 MHz (depends on the region of sale) Auto-regulated radio signal power: ≤ 20 mW Blocking encryption based on the AES algorithm Detector ping interval: 12–300 seconds Frequency hopping
Wings radio protocol	Transmission of a series of photos Transmission of photos by request Checking photo delivery Radio frequency bands: 866.0 – 866.5 MHz 868.0 – 868.6 MHz 868.7 – 869.2 MHz 905.0 – 926.5 MHz 915.85 – 926.5 MHz 921.0 – 922.0 MHz (depends on the region of sale) Auto-regulated radio signal power: ≤ 20 mW Blocking encryption based on the AES algorithm
Protection class	IP50
Operating temperature range	From −10°С to +40°С
Operating humidity	Up to 75%
Anti-sabotage	Forgery prevention Notifications about jamming Tamper to detect back lid opening and unmounting from SmartBracket
Remote configuration	+
Dimensions	163 × 163 × 36 mm
Weight	362 g
Warranty	24 months from the date of sale.
Service life	10 years
Complete set	Hub 2 (2G) or Hub 2 (4G)4 SmartBracket mounting panel Power cable Ethernet cable Installation kit SIM card5 User Guide

---

Download the product information

Manual
