AJAX Hub 2

Manages the security system with visual alarm verifications

• Transmits photos from MotionCam detectors


• Automatically notifies the alarm response company


• Full system control in one app


• Communicates via 3 independent channels

In control of security, not your private life

Hub 2 manages all the Ajax devices in the system to alert users about open doors, broken windows, threats of fire and flooding. If burglars break into your house, Hub 2 transmits pictures from the MotionCam detectors and notifies the alarm response company about the danger. You won’t need to live under the constant supervision of the security cameras to know what’s going on.

• Deters thieves


• Prevents fire


• Detects flooding


• Doesn’t peek

Stress-free

The motion detectors react to dangerous situations as well as simple oversights. A nanny may bring the children home from the school and forget to disarm the security system, which will raise an alarm. With Hub 2, you won’t have to worry in those cases and waste money on the false alarm fines. Open an alarm notification sent by the MotionCam detector to see what happened.

Always in touch

Hub 2 central panel uses Ethernet or one of the 2 SIM cards to guarantee the delivery of the alarms and photos from the secured objects. The channels work in parallel and back each other up in case of emergency.

• Uses 3 independent communication channels


• Delivers alarms in 0.15 seconds


• Transmits photo confirmations even on 2G

Compression and transmission protocols guarantee lightning-fast delivery of the photo series even with weak Internet connectivity. Unlike with the video camera streams, with Ajax, you can evaluate the situation on the secured objects at the 0.5 kB/s Internet speed.

Trouble resistant

With Hub 2, you’ll know immediately if the detector has a malfunction, if someone removed it, if it is damaged, or if its body is open. Even if the lights suddenly go out, the control panel will continue its watch powered by a back-up battery.

• Checks the functionality of detectors at least every 12 seconds


• Alerts about threats, channel interference, or malfunctions


• Operates for up to 16 hours during a blackout

Evolves with every software update

Hub 2 runs on OS Malevich, a real-time operating system. This type of software is used in the systems that can’t afford mistakes—for instance, spaceships and ballistic rocket launchers, or car brakes.

• Protected from cyber-attacks


• Increased functionality with each system update


• Automatically updates over the air

OS Malevich is immune to viruses and protected from cyber attacks. Its architecture allows us to regularly expand the Ajax possibilities over the air without bothering the users.

Jeweller

Hub 2 central panel communicates with the security system devices using radio frequencies on a distance of up to 2000 m.
Two-way Jeweller radio protocol encrypts all of transmitted data. And in cases of interference or jamming, Ajax switches the frequency and notifies you as well as the alarm response company.

• Coverage area up to 2000 m


• Two-way radio communication


• Encryption with a modified AES algorithm


• Frequency hopping

Wings

For parallel visual data transmission from MotionCams, Hub 2 uses Ajax Wings radio protocol. It is a high-speed protocol based on Jeweller technology. Wings received its best features. It also uses a dedicated antenna to improve channel reliability.
Wings guarantees the delivery of photo confirmations even if the signal level is unstable. It uses the built-in algorithms of package checking and re-uploading.

• Transmission of the animated image series


• Communication via additional antenna


• Guaranteed data delivery
  Seamless setup

Seamless setup

It takes minutes to install Hub 2. Connect it to the Internet and plug the power cord. Then scan the QR code using Ajax app. In most cases, your devices won’t require any additional tuning. Hub 2 begins to operate once online.

Download the free app

Scan the QR-code

Control from anywhere in the world

Classification	The radio channel central unit with the support of visual alarm verification detectors
Installation	Indoors
Maximum amount of devices that could be connected to the hub	100
Video surveillance support	Up to 25 cameras or DVRs
Maximum amount of users	50
Maximum amount of rooms	50
Maximum amount of security groups	9
MotionCam detectors support	+
Communication channels	Ethernet Two 2G SIM-cards
Alarm signals	Delivery time: 0.15 sec Notification types: SMS, call, push-notification
Switching between the SIM-cards	4 minutes
CMS connectivity	Contact ID, SIA
The speed of alarm delivery to the CMS	Instant
Software	OS Malevich
Power supply	Main supply: 110−240 V Battery backup: Li-Ion 2 А·h Up to 16 hours of offline operation when the Ethernet is switched off
Wings radio technology	Transmission of visual confirmations Delivery verification of packages
Operating temperature range	From −10°С to +40°С
Size	163×163×36 mm
Weight	362 g
Warranty	Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty.
Complete set	Ajax Hub 2 intelligent control panel SmartBracket mounting panel Power cable Ethernet cable Installation kit User’s guide

---

Download the product information
