Vaillant VC 104/4-7A atmoTEC exclusiv gas wall heater 0010018741

• consisting of high-efficiency pump
• Water pressure sensor and Manometer
• 12 liter expansion tank
• automatic quick vent heating safety valve
• Vario frame
• water-cooled
• atmospheric premix burner
• electronic partial load setting
• Priority changeover valve and storage connection integrated
• Hydraulic and gas-side pre-installation possible
• DIA system with plain text display beleuchtet
• Service panel
• Gas type natural gas E
• Rated power range 80/60 °C
• 4.8-10, 1930 kW
• Storage charging power 10, 1930 kW
• max. heat load
• Heating mode 11, 2000 kW
• min. heat load. 5.3kW
• Standard utilization rate 84% (Hs)/93% (Hi)
• Residual delivery head of the pump 250 mbar
• Flow temperature max. 85 °C
• Electrical connection 230/50 V/Hz
• Flow/return connection G 3/4
• Gas connection G 2000 /2
• Exhaust connection 90 mm height/width/depth 800/440/360 mm weight 39 kg

Power connection (3~/400V) required. The consent of the local network operator may be required. Assembly only by qualified specialist personnel.

Attention: For gas appliances, installation should only be carried out by qualified specialist personnel

Attention: The device may only be installed with the original exhaust accessories from Vaillant !!
