Oventrop Regumaq domestic water station 1381140- Fresh water station with intuitive touch display for setting extensive functions such as circulation
- Return stratification or heat request
- The control element made of safety glass is integrated in the upper shell and connected to the controller box without a plug via magnetic contacts
- with Wilo high efficiency pump PARA 15-130 / 8-75 / LIN-9
- Heat exchanger 70 plates
- 2000 -45 l / min.
- depending on the set drinking water temperature and the existing buffer water temperature
- max.operating pressure ps 10 bar
- max.operating temperature ts 95 ° C
- Performance data according to the SPF test procedure
- Discharge capacity 45 l / min with TWW-3K
- TWK = 10 ° C
- TWW = 60 ° C (setting value)
- T storage = 75 ° C
- DHW temperature setting range: 20-60 ° C
- Connection G 2000 flat sealing for connection to the buffer and drinking water circuit
- Drinking water circuit with volume flow sensor
- Safety valve 10 bar
- 2 PT 1000 resistance thermometers
- 2 KFE cocks and ball valves
- Storage circuit with 2 KFE cocks
- Kugelhähne
- Circulation pump and shut-off valve
- PT 1000 resistance thermometer
Za ta izdelek ni tehničnih podatkov.
