Schell Modus e electronic basin mixer 021740699- HD-M - high pressure mixed water
- Infrared sensor controlled
- Battery operated
- with infrared sensor single-hole fitting
- Temperaturregler
- Infrared sensor electronics
- programmable
- Solenoid valve 6 V
- Strahlregler
- Connection cable 200 mm
- with 2-pin connector
- Protection class IP 65
- 2 flexible connection hoses G 3/8 IG x 450 mm
- with backflow preventer (RV
- DIN EN 1717: EB) and pre-filter
- Battery compartment 6 V
- Protection class IP 65
- 4x AA alkaline batteries 2000
- 5 V
- Fastening material for washbasin mounting
- Adjustment options via near reflex
- Sensor range range (approx. 2 - 17 cm)
- Stagnation flush (off / continuous flow 30 s
- 24 hours after last use)
- Cleaning stop (off / 120 s)
- Flow rate max. 3 l / min independent of pressure
- 1930 pressure match3
- 5 - 5
- 1930 bar
- max.rest pressure 8 bar
- max. operating temperature 70 ° C (briefly e.g. for thermal disinfection)
- Housing material brass compliant with German Drinking Water Ordinance
- Surface chrome
- Connection 2x G 3/8 IG
- Certificates P-IX 29853 / IO
- Noise class I.
- Flow class O
