Bemm Ares bathroom BEA17204801E07M- for purely electrical operation including heating element with medium temperature controller for heating towels and textiles and for room heating
- 23 mm horizontal round tubes connected to 30 x 40 mm vertical semi-oval tubes that are smooth all round
- with 2-3 openings for towels
- filled with heat transfer fluid (antifreeze down to -6 °C)
- The heating rod with controller is fitted as standard in the right collecting pipe
- by turning the radiator and turning the controller, the Bathroom Radiators can also be installed with the heating element on the left
- Unused connections sealed watertight with dummy plugs DN 15 with hexagon socket
- Heating rod with thermal fuse and stainless steel immersion body with DN 15 connection thread with O-ring
- Thermostat with approx 1930
- 8 m connection cable and safety plug
- Mains voltage 230 V/50 Hz
- Class I
- IP44
- with regulation of the medium temperature
- Setting range 20-65 °C (surface temperature approx. 18.50 °C)
- Timer for 3 different boost functions (max. heating capacity to 65 °C from the set target temperature)
- Standby mode (without heating function)
- pilot light
- Housing and connection cable made of white plastic
- 115*70*38mm
- Surface powder-coated DIN 55900 and baked at approx. 180 °C
- standard Zubehör 3x wall fixings with screws and dowels
- meet AK 3 according to VDI 6036
- Corresponds to the guidelines of the statutory accident insurers (GUV)
